| Quantity: | |
|---|---|
No. | Item | Nominal parameter | Instruction |
1 | Nominal capacity | 100 Ah | |
2 | Min capacity | 99Ah | |
3 | Nominal Voltage | 25.6V | |
4 | Charging cut-off voltage | 29.2V | |
5 | Discharging cut-off voltage | 20.0V | When the battery energy is exhausted, charging is prohibited beyond one week |
6 | Recommended charging current | 20A | |
7 | Max continuous charging current | 75A | Max continuous charging power 1.5KW |
8 | Max pulse charging current | 100 A | |
9 | Recommended discharging current | 20A | |
10 | Max continuous discharge current | 75A | 1.5KW Max continuous discharging power 1.5KW |
11 | Max pulse discharging current | 100 A | |
12 | Charging cut-off condition | 5A | Cut-off current 5 A |
13 | Operation temp (charging) | 0~45℃ | |
14 | Operation temp (discharging) | -20-55 ℃ | |
15 | Storage temp | 10-40℃ | Disconnect the load at the battery output terminal if more than 1 week storage |
16 | Storage humi | <75%RH | |
17 | Weight | about 23kg | |
18 | Internal resistance | <50m。 | AC internal resistance (ACR） |
19 | Cycle life | ≥80% capacity after 2500 times cycle life testing | At 25±2℃ operation temp, 2500 times charging and discharging Charging voltage/current: 29.2V/20A, cut-off current ≤5A Discharging current: 20A (cut-off voltage 20V) Cycle interval time: 3 0minutes |
Size: 530x270x225 (LxWxH) mm
