No. | Item | Parameter | Description |
1 | Nominal capacity | 200Ah |
|
2 | Minimum capacity | 194Ah |
|
3 | Nominal voltage | 12.8V |
|
4 | Charging cut off voltage | 14.6V |
|
5 | Discharging cut off voltage | 10V |
|
6 | Recommend charging current | 40A | 0-15℃ |
7 | Maximum continuous charging current | 50A | 25-40℃ |
8 | Recommend discharging current | 40A | -20-15℃ |
|
| 60A | 15-60℃ |
9 | Maximum continuous discharging current | 100A | 25-50℃ |
10 | Charging cut off condition | 10A |
|
11 | Operating temperature（charging） | 0~55℃ |
|
12 | Operating temperature（discharging） | -20~60℃ |
|
13 | Storage temperature | -20~45℃ | 1 month |
|
| -10~35℃ | 6 months |
14 | Storage humidity | ＜65%RH |
|
15 | Weight | 约21.7kg |
|
16 | Internal resistance | ＜20mΩ | 1000 Hz condition |
17 | Communication | Blue tooth |
|
