Battery Specification Parameters
No | Item | Rated parameter | Remark |
1 | Rated Capacity | 100Ah | Standard charge and discharge capacity*1 |
2 | Min Capacity | 98Ah | Standard charge and discharge capacity*1 |
3 | Nominal Voltage | 76.8V | |
4 | Standard charging voltage | 87.6V | |
5 | Discharging cut-off voltage | 60.0V | The battery must be charged promptly after it is depleted; it is prohibited to leave it unused for more than one week. |
6 | Recommended charging current | 50A | |
7 | Maximum Continuous Charging Current | 100A | |
8 | Maximum Charging Current（pulse） | 105A | Continuous time≤10S |
9 | Recommended discharge current | 50A | |
10 | Maximum Continuous discharging Current | 150A | |
11 | Maximum discharging Current（pulse） | 300A | Continuous time≤10S |
12 | Condition to stop charging | 5A | Cut-off current≤5 A |
13 | Using temperature（charge） | 0~55℃ | Discharge conditions refer to those described in 3.4 |
14 | Using temperature（discharge） | -20~60℃ | Discharge conditions refer to those described in 3.4 |
15 | Storage temp | -10~35℃ | For storage lasting more than 1 week, the load connected to the battery output terminal must be disconnected.*1 |
16 | Storage humi | <75%RH | |
17 | Weight | 63kg or so | |
18 | Internal resistance | <20m Ω | （ACR） |
19 | Aerosol fire extinguisher | ≥170℃ | warm boot |
Annotation 1
Standard discharge：At room temperature(25±2℃), discharging with constant current 50A until the voltage is 60V(or single battery voltage 2.5V±0.025V), then stops discharging
Standard charge: At room temperature(25±2℃), charging with constant voltage 87.6V / constant current 50A until the current is 5A, then stops charging
Battery Usage: The battery needs to be fully charged and discharged once every 2 months. If not used for more than 1 week, the load connected to the battery output should be disconnected.
